Specifications:
ITEMS Unit YV200B YV200E YV200E+C
Machine capacity
Max. swing diameter mm ø 400 ø 400 ø 400
Max. cutting diameter mm ø 250 ø 250 ø 250
Max. cutting height mm 200 200 250
Spindle
Spindle speed rpm 50~3500 50~3500 50~3500
Spindle bearing diameter mm 80 80 80
Drilling & tapping mm N/A N/A ø 12/M10(FC)
Spindle nose mm A2-6 A2-6 A2-6
Turret
Turret type   Gang Tool 8 station V.D.I 40
Number of tools pcs 4 8 8
Tool shank size mm 25,ø 40 25,ø 32 25,ø 40
X-axis and Z-axis
X-axis travel mm -40;+250 -40;+160 -40;+210
Z-axis travel mm 450 400 450
X-axis rapid travel m/min 12 12 12
Z-axis rapid travel m/min 24 24 24
Motor
Spindle motor kw α P22 11/15 α P22 11/15 α P22 11/15
X-axis servo motor kw 1.6 1.6 1.6
Z-axis servo motor kw 3 3 3
Hydraulic motor kw 2.2 2.2 2.2
Coolant motor kw 0.5 0.5 0.5+1
Motor for drilling & tapping kw N/A N/A 2.2/3.7α2
Measurement
LxW mm 2880x1530 2880x1480 2920x1480
Machine height mm 2460 2460 2520
Net weight kg 4100 4400 4500
Total power consumption KVA 25 25 30
